M1218CL2-E - Module, Refrigerant AC/Heat Pump Coil (6 Row) (HP)

Ships in 24x22x14 inch pkg; 60 lbs

Difference between CL1 and CL2: CL2 uses chatleff like other modules, uses A02732-K01 Valve.

Description:

• This is the 1 to 1.5 ton left hand 6 row refrigerant coil module with R410A TXV and stainless steel primary drain pan
• The Unico System uses less than one-third of the space in the built environment than a traditional system
• It can deliver up to 9 tons of air conditioning in the same space as a 3-ton traditional unit

General Features:

• Modular construction
• Multiple configurations
• Use as cooling only or heat pump
• Painted options available
• Enhanced Aluminum fins
• Copper tubes
• Stainless steel drain pan
• Includes: TXV (shipped loose), EZ trap (shipped loose), Anti-frost switch
