M1218CL1-C - Unico Module, Hydronic, Chilled Water Coil
SHIPPING
DIRECT SHIP USA/CANADA (FROM MISSOURI)
M1218CL1-C — a chilled-water coil module.
Key features
- 1-1.5 Ton Modular Unit (FCU).
- All TXVs are R410-A with Flare Fitting.
Specifications
| Nominal Capacity | 1 to 1.5-ton (3.5 to 5 kW) |
|---|---|
| Dimensions | 24 in x 22 in x 14 in |
| Weight | 60 lb |
| Air Flow Range | 100 to 500 CFM (170 to-850 m3 /h) |
Documents
- M1218CL1-C Coil Dimensional Data (PDF)
- Dimensional Data (M1218CL-C) (PDF)
- M Series Chilled Water Coil Module (PDF)
- M-Series Heat Pump Installation Supplement (Bulletin 30-024) (PDF)
- M1218CL1-E Coil Dimensional Data (PDF)
- M1218CL1-A Coil Dimensional Data (PDF)
- Dimensional Data (M1218CL-E) (PDF)
- M1218CL1-H Coil Dimensional Data (PDF)
- (29 additional document(s) available — contact us or see the resource library)
Ships in 24x22x14 in pkg; 60 lb
