Unico, Inc.

V3036B-1EC2BHC - Vertical Air Handler, SCB, Variable Speed, 120V - 208/230V,3 Row Coil, (AC) with HWC, E-Coated

$4,526.20 $7,312.45

Ships in 27x25x44 inch pkg; 239 lbs

This is our Coated V-Series one piece fan coil unit for vertical up flow applications in a closet or basement. This model is our 2.5 to 3 ton model with 230 volt ECM blower and cooling DX coil which includes a R410A TXV and a hot water coil. It can be connected to a 2.5 to 3 ton condensing unit from a third party.

Unico Model 3036
Tonnage 2.5-Ton, 3.0-Ton
Model Series V-Series
Motor Type EC
Nominal Capacity 36,000 Btu/hr (10.5 kW)
Coil Type Refrigerant, Hot Water
Power Supply 208-230/1/60
Brand Unico
Installation Orientation Vertical Upflow
Refrigerant Type R-410A
Connectivity USB
Certifications ETL
