Unico, Inc.
V2430B-1EC2EH - Vertical Air Handler Unit, 2430, 230V, 4 Row Coil, (HP) with HWC
$4,262.60
$6,689
Ships in 27x22x44 inch pkg; 210 lbs
This is our V-Series one piece fan coil unit for vertical up flow applications in a closet or basement. This model is our 2 to 2.5 ton model with 230 volt ECM blower and heat pump DX coil which includes a R410A TXV and a hot water coil. It can be connected to a 2 ton or 2.5 ton heat pump unit from a third party.
| Unico Model | 2430 |
| Tonnage | 2.0-Ton, 2.5-Ton |
| Model Series | V-Series |
| Motor Type | EC |
| Nominal Capacity | 30,000 Btu/hr (8.7 kW) |
| Coil Type | Refrigerant, Hot Water |
| Power Supply | 208-230/1/60 |
| Brand | Unico |
| Installation Orientation | Vertical Upflow |
| Refrigerant Type | R-410A |
| Connectivity | USB |
| Certifications | ETL |
